Acquisitor circuit is compose of power circuit, RS485 communication, PLC, MCU and infrared communication. Use single phase supply, upstream channel with low voltage PLC, downstream channel with RS485, it can access 8 energy meters. Reading energy meter data by IR through acquisitor and reading or setting acquisitor parameters.

• PLC AMR

• Automatic PLC reply function

• Time synchronization

• RS485 communication
